YXP96 Mobile Plug-in Thermal Imaging Camera


The YXP96 infrared thermal imaging phone module can be paired with a smartphone for infrared thermal imaging temperature measurement. It is compact, portable, and easy to operate. With a resolution of 96*96 pixels, it provides detailed image quality for inspection. Manual focus function, so that you can see details more clearly on the basis of excellent imaging. With a 25Hz frame rate, the video runs smoothly without lag, enabling you to quickly and conveniently identify hidden issues. The wide range of -20 ~ 550℃ covers a wide range of applications, It also allows real-time temperature measurement through the mobile app, with features such as night vision, photo capture, and video recording, making it a versatile assistant for your daily work, home life, and adventurous travels.

Category:

Outdoor viewing thermal imager

Key words:

YXP96 Mobile Plug-in Thermal Imaging Camera

Product Features

Main features of the product:
(1) -20℃~550℃ Wide temperature measurement range
(2) 96×96 infrared resolution
(3) 25Hz frame rate, Provides smooth visuals and real-time temperature data collection.
(4) Multiple color palettes, Selectable based on different scenes and requirements
(5) Real-time temperature tracking/alarm
(6) Automatic screen rotation
(7) Multi-point Intelligent Measurement
(8) Multiple Image Modes Available: Infrared/Picture-in-picture image mode

Technical parameters

Model YXP96
Temperature Range -20℃~550℃
Infrared Resolution 96×96
Measurement Accuracy ±2°C or ±2% of reading (whichever is greater, Ambient temperature 25°C)
Measurement Resolution 0.1℃
Detector Type Oxide Vanadium Thermal Imaging Sensor
Measurement Modes Industrial temperature measurement
Emissivity 0.01~1.00(default 0.95)
Infrared Wavelength Range 8~14μm
Pixel Size 12μm
Spatial Resolution 8.89mrad
Focal Length 1.35mm
Frame Rate 25Hz
Thermal Sensitivity (NETD) ≤40 mK
Focusing Method Fixed Focus
Field of View (FOV) 50° × 50°
Temperature Unit ℃/℉/K
Temperature Display 3 temperature measurement points (Center Point, Max Temp, Min Temp)
Temperature analysis 3 points, 3 lines, 3 rectangles
Isotherms Auto
Center point temperature measurement
High/Low Temperature Tracking
High/Low Temperature Alarm On-screen marker alarm, Audio alarm
Color Palettes Red hot, rainbow, lava, iron red, black hot, white hot, etc., the same as the current settings
Image Modes Thermal imaging, picture-in-picture
Photo/Video Recording
Image/Video Format JPEG/MP4
Product Interface Type-C
Supported Languages Simplified Chinese, Traditional Chinese, English, Spanish
Supported Mobile Systems Android, compatible with the existing YaoGuang Zhigan APP
Operating Temperature -10~50℃
Operating Humidity 10%~90%RH (Non-condensing)
Storage Temperature -20~60℃
Certifications CE、FCC、ROHS
Other Specification
Product Dimensions 18g
Product Weight 44mm×25mm×10mm
Standard Accessories Color Box, User Manual

Application Scenarios

New energy industry

New energy industry

Field exploration

Field exploration

Security monitoring

Security monitoring
