YXM335L Handheld Observation Thermal Imaging Camera
The YXM335L handheld observation thermal imaging camera is a multifunctional thermal imager that integrates basic observation, searching, and reconnaissance capabilities. In low-light or no-light environments, it leverages its superior thermal imaging abilities to enable long-distance target observation and environmental patrols.
The YXM335L adopts an ergonomic design, making it lightweight, easy to operate, and equipped with outstanding nighttime reconnaissance capabilities. It is widely used for patrolling, hiking, and travel. As a monocular handheld infrared telescope, the YXM335L delivers clear and detailed thermal images, making it an ideal device for outdoor activities.
Category:
Outdoor viewing thermal imager
Key words:
YXM335L Handheld Observation Thermal Imaging Camera
Product Features
Main features of the product:
1. 384×288 infrared resolution
2. 50Hz Frame Rate
3. 35mm Focal Length
4. 6 Color Palettes
5. 1200m Measurement Distance (Dedicated Button)
6. 1x/2x/4x digital zoom with adaptive scaling
7. Electronic Compass Function
8. Multiple Reticle Options
9. 32GB Built-in Storage
Technical parameters
| Model | YXM335L | ||
| Detector | Detector Type | Uncooled VOx Infrared Focal Plane Detector | |
| Infrared Resolution | 384×288 | ||
| Infrared Wavelength Range | 8~14μm | ||
| Pixel Size | 12μm | ||
| Frame Rate | 50Hz | ||
| Thermal Sensitivity (NETD) | ≤ 35mK @F#1.0, 300k | ||
| Lens Focal Length | 35mm | ||
| Spatial Resolution (IFOV) | 0.34mrad | ||
| Base Magnification | 3.3 | ||
| Lens | Focus Adjustment | Manual Focus | |
| Field of View (FOV) | 10.7° x 8.0° | ||
| Display | Screen Size | 0.39inc | |
| Resolution | 1024 x 768 | ||
| Digital Zoom | 1x 2x 4x | ||
| Viewing Angle Adjustment | -5°~+5° | ||
| Detection Distance | Human (m) | 1653m | |
| Wild Boar (m) | 1458m | ||
| Vehicle (m) | 4375m | ||
| Recognition Distance | Human (m) | 413m | |
| Wild Boar (m) | 365m | ||
| Vehicle (m) | 1094m | ||
| Basic Functions | Range | 1200m | |
| Picture-in-Picture Mod | √ | ||
| Color Palettes | White Hot, Black Hot, Rainbow, Iron Red, Red Heat, Low-Light Mode | ||
| Photo/Video Recording | √ | ||
| Image/Video Format | Image: JPEG / Video: MP4 | ||
| Languages | Simplified Chinese, Traditional Chinese, English | ||
| Storage | 32G | ||
| Interfaces | USB Port | Type-C (Supports Exporting Images & Videos) | |
| Battery | Battery Type | 2×18500 Batteries, 4000mAh | |
| Charging Time | ≤4h | ||
| Operating Time | ≥6 | ||
| Total Power Consumption | ≤1.8W | ||
| Environmental Conditions | Operating Temperature | -20℃~+60℃ | |
| Operating Humidity | 10%~90%RH | ||
| Storage Temperature | -30℃~+70℃ | ||
| Shock Resistance | 1000G（Target） | ||
| IP Rating | IP67 | ||
| Certifications | CE、FCC、ROHS | ||
| Other Parameters | |||
| Product Weight | ≈710g | ||
| Product Dimensions | 220mm×77mm×62mm | ||
| Standard Accessories | Color box, user manual, Type-C data cable (1m), carrying pouch | ||
Application Scenarios
Security monitoring
Building diagnosis
Scientific research
